Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 118

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 118
is used, having a single coil and commutating the secondarycurrent. The inlet and exhaust valves may be removed from anycylinder head by loosening a single nut. The crank shaft and crankpins are hollow for lubrication purposes. This motor is believed to be the lightest for its power ever… … H4 EXPLOSIVE MOTOR POWER AND APPLIANCES.
