Figure 48.—Section from Bridge Deck to Top of Wheelhouse ofStandard Wooden Steamship. FRAMES The frames are double saAved, spaced 36 centerto center, separated at the butts with 2-inch chocks,and each butt fastened with II/4 treenail. The frames are laid out from the moulds, as SHIP CONSTRUCTION 101 … 5YR PUANKIMO Figure 49.—Section Ttiroiigh Poop. 102 COURSE IN WOODEN BOAT AND SHIP BUILDING
