A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 125

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 125
122 COURSE IX WOODEN BOAT AND SHIP BUILDING … MACHINES AND LABOR-SAVING DEVICES 123 Figure 67 shows the same piece after sixteencuts have been completed, the lower part beveledtwo ways, and the sides surfaced. It leaves themachine as shown in Figure 68, practically fin-ished, requiring comparatively little time with

Shipbuilding
