136 COURSE IN WOODEN BOAT AND SHIP BUILDING … a5 RAISING THE FRAMES 13T are let into the outside of the frames and inclinedat an angle of 45 degrees each way. The diagonals are connected to the top belt bytwo %-iiicli rivets and at each crossing by one1-inch rivet, and also fastened to each frame timberby one 1-inch countersunk bolt. They…
