A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 146

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 146
I PLANKING AND FINISHING 143- … 04I 144 COURSE IN WOODEN BOAT AND SHIP BUILDING ship, beginning with 5-inch by 10-inch, then 5-incHby 9-inch, and 5-inch by 8-inch, the topside plank-ing being 6-inch by 9-inch. The lengths of the planking are jointed withsquare butts on the frames, with the seams out-gauged for calking. The circle…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
