A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 21

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 21
rame lines outside the timber at anypoint in the vessel. Frame lines forward of themidship section are on the right of the center line;aft of the midship section on the left of the centerline. TABLE OF OFFSETS The table of offsets exhibits the distances froma center or base line. These offsets are…
