Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 259

An illustration from Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice, 1922, leaf 259 — convenient scales of pressure and volume for the com-bined diagram, Fig 97, and lay them off on coordinate paper.Draw in the atmospheric pressure line. Locate the vertical line 1-2, Fig. 97, at the volume graduationcorresponding to the clearance volume, Vi. Locate the vertical3-4 at the volume… … /4 7/£. Fig. 96.—H.P. Diagram. /47/A Condenser Pressure*Fig. 95.—L.P. Diagram.

Mechanical engineering

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
