Figure 7.—Moulds for Stem. STEM AND STERN CONSTKDCTION 31 picking up the lines is shown in Figures 9 and 10.On the floor is shown the full size layout of thestem and stern construction shown in Figures 5and 6.Place a series of tacks with the heads resting … Figure 8.—Moulds for Stern. on the required line, Figure 9. The heads of thetacks should be driven into the floor slightly, toprevent them from moving out of place. Place a piece of stock wide enough to cover themember, with the grain of the wood running in thedirection that will show the least…
