of the ruddertrunk. The lines 1, 2, 3, 4 and 5, in-tersecting CD are transferredover to the expanded lines par-allel to ELG as shown by dot-ted lines running from CD to 1,2, 3, 4 and 5, and a battenpassed through these points willgive the desired cut of ruddertrunk from the stern post to thecenter… … - fy<i.//z.-~ 106 LAKE SHIP YARD METHODS OF
