A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 49

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 49
4e COURSE IN WOODEN BOAT AND SHIP BUILDING The sheer, diagonal, and keel lines are trans-ferred from the floor to the moulds. These lineswill be needed in lining up and setting the frames^and for locating the beveling spots and running-the ribbands. Surmarks.—The marks on the moulds showing … Figure 20.—Pipe Details of Steam Box. the intermediate bevel stations, or where the diag-onal lines cross the futtocks, are called surmarks. STEAM BOX The futtocks, ends of ribbands, and plankingwill need to be steamed in order to bend them tathe required shape. The size of the steam boxrequired is…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
