A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 55

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 55
Figure 23.—Bending Timbers. as 1st, 2nd, 3rd, etc., diagonals, and give thestations or surmarks of the ribbands, which areplaced around the timbers to give support to thevessel while in frame. 52 COURSE IN WOODEN BOAT AND SHIP BUILDING SHCER Line SheerLine. … MM Figure 24.—Method of Developing Bevels on Diagonals. FDTTOCKS AND FRAMES BEVELING FRAMES The edges of the frames must be beveled, so thatwhen the planking is bent around them they willfit tight at all points. These bevels are developedon the diagonal lines, as shown in Figure 24. Draw two lines…

Shipbuilding
