A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 61

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 61
tock is roughed out, fitted and fastened together,and then lined from the moulds. Figure 31 shows a strap frame boat. This islighter construction. False frames are first in-stalled, ribbands run, and the boat faired up. Theframes are bent around a form, the ends tied to-gether as shown in Figure… … Figure 27.—Sawing Timbers. FUTTOCKS AND FRAMES 39

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
