metrically opposite spaces, but itwill be observed that, although each space contains a coil,only half of the commutator bars can be c(mnected with thisseries. Therefore, a second series of coils is placed uponthe armature, as shown in dotted lines. These coils arearranged in the spaces at the side… … ELECTRIC LIGHTING. 521 The manner of connecting the terminals of these coilswith the commutator bars is clearl) illustrated in Fig. 505,which is a perspective view of the end of the armature. The Fig. 503.
