^ of themagnet to the other, and at the ends will be formed sym-metrical, approximately semicircular curves. When a Fig. 605. … The Magnetic Field. cylindrical piece of iron, representing the armature coreof a dynamo, is inserted between the poles of the magnetin the place usually occupied by the armature, the lines aredeflected inward, becoming perpendicular to the peripheryof the armature. The iron representing the…
