Kaye, G. W. C. (George William Clarkson), 1880-1941 · London, New York [etc.] Longman's Green, and Co. · leaf 236
Laue spots is a direct con-sequence of the fact that the incident pencil of X rays isnot strictly parallel but slightly conical, and so the reflectedpencU, which is obliquely received on the photographicplate, shows an elliptical section. Elliptical Loci of Laue Spots. With prolonged exposures,… … Fig. 1.08.—Construction demonstrating elliptical loci of Laue spots. central spot. These ellipses, which are nearly circular, aresections of circular cones having the incident beam as agenerator. The elliptical locus is a consequence of the factthat the various systems of parallel planes which can…
X-rays
