lines, and consequentlyvanishing points on them. In each case the horizon andthe eye are given, and the V.L. of the particular planeand the eye in relation to it, with the working shown.The method of getting the vanishing lines, having beentreated in paragraphs 32 to 38, is not given here. In each… … Fio. 85.—^A horizontal plane, two lines vanishing at 40° to right,and two at 50° to left.
