.P. This gives E.S.3, which is the radiatingpoint of the shadow of the line C. We draw from R.S.3through the end of C, namely C, and limit the shadowby a ray from the light. To prove this, point C is treated like point A, and its shadowis found by a vertical line.This is shown in dotted… … FiG. 112.—A semicircle standingvertically, its shadow cast by anartificial liglit. Shadows cast by Artificial Light 147
