. These linesall vanish to C.V., and the shadows of none happen to beseen. The object or arch on its left side illustrates theshadows obtained on the ground plane of lines which donot vanish. From point A upwards is a vertical line;from the top of that proceeds an inclined line for a shortdistance,… … vertical and inclined surfaces of the inner side of thesupport on the right. The example includes, therefore,several instances. i6o Perspective Eeturning to the shadows on the left side. If weapply our rule— To find Tanishing point of shadow (V.S.) of AB, drawthrough sun parallel to AB, i.e.…
