Hatton, Richard G · London, Chapman & Hall ld. · leaf 215
Fig. 135.—The mirror vertical and perpendicular to the piolure.The object in angular perBpective. i8o Perspective blackened, gains us V.P.3. To get the inclination of theV.P. of reflection over V.P.3, a new eye is required. It … A~erial Perspective i8i is eye 3, and the same angle is set up at it as was setup at eye 2. The perpendicular CD has to be measured by a measur-ing point, M.P.I. 60. Aerial Perspective. The only fact of aerial perspective which the studentneed trouble about—and it is of comparatively littlevalue—is…
Perspective · Drawing
