Hatton, Richard G · London, Chapman & Hall ld. · leaf 272
ems 237 be drawn with, grace, and will most probably extendbeyond the point B, so that the greatest width willdepend on the good drawing of the curve rather thanthe accurate perspective working of the lower curve ofthe platform; only the front need be drawn, though it isno harm to draw the whole.… … Fio. 180.—The square base of the cube found on the top of the circle. whether he wishes the invisible parts put in by dots,but none of his diagrams have them. The next item is to place a cube on the top of theplatform, the axis of the cube presumably coincidingwith the axis of the platform. We have…
Perspective · Drawing
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
