j in the G.P- will always lie in lines atright angles to X^Vj irrespective of its distance from XiVj, and the long edges willboth be parallel to X^v^. Points on the G.P- corresponding to Xj will always be on one of the long edges,and points on the G.P- corresponding to V, will be on the other, as… … Pig. 16. Fig. 16 is the application of the two preceding figures. The only additional pointis Al, which is the perspective representation of a point A situated in the line whoseperspective representation is X^Vj. To avoid confusion, as in the previous figure theoriginal line is not shown.- a^ is…
