Adams, Henry · London, New York [etc.] Longmans, Green, and Co. · leaf 106
13 … F/g. J06 these bending moments have to be replaced by virtual forces. Theframe diagram of a queen-post truss with structural load and windpressure is shown in Fig. 806. To work out the stress diagram, Fig.307, proceed as follows:—Set down the load line 1 to 7, and join 1—7,then 2—1.5, 6—15 ; 15—8…
Building · Structural analysis (Engineering)
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
