Adams, Henry · London, New York [etc.] Longmans, Green, and Co. · leaf 136
2S Cons per sq In … the former giving the direct loads and the latter the overturning forceon the walls. The bending moments and other stresses would be those 122 THE MECHANICS OF BUILDING CONSTRUCTION due to Fig. 384, and not to Fig. 392, because the bottom gussets wouldbe absent. If the walls are not rigid, it is…
Building · Structural analysis (Engineering)
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
