c-/47./S tion it offers to the light.As a railway girder the loadwas applied to the topflange as in Fig. 203, wherethree bays only are shownto illustrate the principle,the usual number beingeight or ten. The stressdiagram is given in Fig.204. Two girders of thiskind, with cross ties andsteel… … LATTICE GIRDERS 61 it is called a through bridge. One such girder reduced to three bays,
