Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 102
WALL AND WINDOW SECTION PLAN—SHOWING ALSO WALL CONSTRUCTION … CROSS SECTION THROUGH ICE CHAMBER AND COOLING ROOM VERTICAL SECTION THROUGH ICE CHAMBER PLATE 89—SMALL GOLD STORAGE HOUSE Floor plan, vertical sections showing complete and cold air falls, a continuous circulation of details of construction and arrangement; also cooled air passes through the…
Building
