Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)

Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 147

An illustration from Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features, 1911, leaf 147
Qooo COMSWUCJIOH. PLATE 133 A—CORNICE CONSTRUCTION, GOOD AND BAD At B is illustrated the usual method of cor-nice construction for cottages where the ceilingis lower than the plate. The spaces between thestudding are left open and the cold winds circu- late freely. The result is a cold house. At F… … (eXTSEIOIS)
