Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)

Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 168

An illustration from Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features, 1911, leaf 168
Door 3£ … SINGLE SLIDING DOOR Cross section showing details of constructionfor a single door to slide one way. A removablebumping piece closes the pocket on one side. Thispiece is the thickness of the jamb; and the jointsare concealed with the stop mouldings as shown.

Building
