Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)

Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 180

An illustration from Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features, 1911, leaf 180
^js^cr/or/i … PLATE 166—SELF-SUPPORTING CAMBREL BARN ROOFS Cross section showing details of construction Also cross section of one story cow stable equipped and roof framing of a medium sized gambrel with feed and manure overhead track carriers, roof dairy barn with self-supporting roof so that Note sanitary,…
