Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 67
FIG. 83. … /I ■ A y ^\^ --^ zn:^ =nl PAMBl^. T-ICi. 66. PLATE 55—DOUBLE HUNG BOX FRAME WINDOW Construction in frame wall. The box frameis formed with back casing (A) completing thebox and insuring a rigid pulley stile and conse-quently accurately fitting sashes. The extra spacerequired for window screen and…
