Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 93
Construction in 16 inch brick wall. Pivoted head. Fig. 193, vertical section taken through thecasements should not be used in locations ex- window at the axis of the sash, showing the win-posed to severe driving rain storms, as it is prac- dows closed by means of the solid lines and opentically… … PLATE 81—VERTICALLY PIVOTED CASEMENT WINDOW Construction in 16 inch brick wall. It is diffi- izontal section through the window, showing the cult to make this type of window weather-tight, position of the sash, both when open and when especially for windows in exposed positions. Fig. closed. Fig.…
