Young, George, jr, Baxter, Hubert Eugene, joint author · New York, Macmillan · leaf 217
Fig. 182 198 DESCRIPTIVE GEOMETRY [VIII, § 174 intersection of the envelope with H is a, curve, tangent to thesuccessive projections of the right section, which determinesthe projection of the surface. … FiQ. 183 VIII, § 175] CURVED SURFACES 199 II. The General Method. In Fig. 183, let it be requiredto draw the projections of the surface shown at (o) when itsaxis is inclined to H and V as indicated by the Hne he. The general method which will be followed consists in draw-ing the projection of the…
Geometry, Descriptive
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
