Young, George, jr, Baxter, Hubert Eugene, joint author · New York, Macmillan · leaf 315
he openings required for a shaft, the rightsection of which is an equilateral triangle, \\ on a side. EXERCISE SHEET LXXVIII (§§184-187) Use a large, sheet, placed vertically and divided into four parts asshown on p. xii. Omit HA lines. Construct an elevation and a root plan similar to Fig. 197 for… … APPENDIX 297 Letters on Figure 197Case ahcdejgh 1 40 20 20 40 25 25 10 10 2 40 20 20 40 12 30 8 12 3 40 20 20 40 25 10 12 8 4 Using dimensions as in 2, above,let the low wing be revolved on 0until the angle is 60°. [Note. Donners similar to those in Figs. 192 / and 198 may beadded if desired. Let…
Geometry, Descriptive
