should be no stones withre-entrant angles at the points I and J. That joints of a stonesituated in two faces, as at the angles H and Gr, are perpendicularto the faces. Note the arrangement of the stones in the two coursesat the points I and J. The upper stone of the buttress shouldextend at least 6… … to a plane. Cut the bottom face by use of its pattern, and fromit work the other faces by use of their respective bevels, on whichthe widths of the several faces are marked. The patterns of thefaces may be used as checks on the work. 59, In a structure of this kind it is best not to scale dimen-…
Stereotomy
