he longitudinal frames in the double bottom are thenworked in short lengths (intercostally) between the transverse frames. 2 b ;7o XAVAL ARCHITECTURE. [chap. IX. Very similar arrangements have been carried out in some cruisers ofrecent construction and of moderate dimensions. The discontinuityof… … side longitudinals (AA) deep transverse frames or partial bulkheadsare commonly fitted at intervals of 10 or 12 feet, and carried up tothe lowest complete deck. The outline of such a strengthener isindicated by dotted lines in the diagram. From this brief explanation it will be seen that the…
