Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 26
SHIP CONSTRUCTION IS Fig. 12 shows mold for bilgebrackets which is used for 85per cent of the vessel; beyondthat, at both ends, molds aremade for each bracket. Twoplates are obtained from eachniold at the ends beyond mid-ship. Fig. 13 shows the mold forthe channel frames at side; bshows the mold…
Naval architecture · Ships, Iron and steel
