Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 88
through the keelwill be used for the flange tothe keel plates. The top an-gles for the center keelsonhave a uniform pitch through-out on the keelson plate andone side of the tank which is water-tight, the other side is 8 diameterpitch of rivets for connecting the tank top plating to the center… … 78 LAKE SHIP YARD METHODS OF The keel plate liners which are fitted between the keel plate buttstraps and under the center keelson bottom angles are marked frommolds, the holes for same being obtained from the strips which areused for marking the bar rivet holes in the keel plates. The sameprocess…
