Mechanical and marine engineering science ... Specially written as a handbook to the Board of Trade examinations for extra-first-class engineers (1909)
Somerscales, A. N · Glasgow : J. Munro; London, Simpkin, Marshall, Hamilton, Kent · leaf 228
Fig. 79- … BEAMS. 22^- Now if a weight, W, is hung from the end of the cantilever,two movements are noticeable. Firstly, the beam is tipped downat the outer end, so as to compress the lower spring and stretch theupper one. And secondly, the beam is pulled down bodily so as tomake both springs take an oblique…
Naval architecture
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
