Text-book of theoretical naval architecture (1889)
Attwood, Edward L. (Edward Lewis), 1871- · London, New York [etc.] Longmans, Green, and Co. · leaf 208
eed to find the C.G. ofthe bottom plating as indicated in the following table. Thearea is obtained by putting the half-girths (modified as already This assumes the plating of constant thickness. Plates which arethicker, as at keel, bilge, and sheer, can be allowed for afterwards. Calculation of… … Fig. 83. of the sections below the L.W.L., which distances are measuredoff from the curve CC and are placed in column 6. Theremainder of the work does not need any further explanation. Calculation for Area and Position of C.G. of Bottom PlatingFOR A Length op 244 Feet. Modifiedhalf-girths.…
Naval architecture
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
