Barrows, F. W. (Frank Wilson), b. 1853 · New York, N.W. Henley Pub. Co. · leaf 71
Fig. 4. 70 PATTERNMAKING. may be made dose together or even overlapping near thesides of box so as to remove more of the wood shown abovegroove marked i. Fig. 4 shows a very common way of sawing wedges.The gauge is made with one side shown by dotted line … Fig. s. having the required taper. Place the opposite side againstthe fence b, hold one edge of the piece to be cut against thetemplet, letting the end toward you rest against the shoul-der formed by the piece i, which is fastened to the backend of templet, then by moving the stuff over the saw…
Patternmaking
