Ballard, William Cyrus, Jr · New York [etc.] McGraw-Hill company, inc. · leaf 72
e the iron becomes nearlysaturated, that is, it will only sMghtly respond to furtherincreases in current. This changes the characteristics ofthe high-frequency coil also and hence the current in theantenna. This effect is varied to a greater or less degreedepending upon the value of current flowing… … mkrophona /ron core Fig. 23.—Magnetic modulator showing connections to power tubeoscillator and antenna. The current-carrying capacity of this apparatus is notlimited as was the case with the microphone and it can beemployed to modulate very, large outputs. For simplicity ofoperation it can hardly…
Radio
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
