illlll FIG. 638.—CAPACITY TEST. the condenser with that produced by the charge of the cable, a directcomparison may be made between the capacity of the cable and thatof the condenser. Thus, if with the m shunt the discharge fromthe condenser gave a deflection of 100 scale, divisions, the capacityof… … FIG. 639.-CAPACITY TEST FOR CABLE. the discharge of the cable produced a deflection twice as great, we would know that the capacity of the cable was 2 X -^ ^= - micro-farad. 1° 5 Convenient connections for making capacity tests are shown inFig. 640, where G is the galvanometer, .S the shunt, C the…
