Fig. 234. Fig. 235. j^ ^^^ 235. (c) After the apparatus is dried, mount the coil with its axis hori-zontal, and the two platforms of cardboard also In a horizontal plane.Send the current through the coil, and strew filings upon the card-board. Note the tendency of the filings to arrange themselves… … MAGNETIC EFFECTS OF THE CURRENT 273 lines of force. This tendency may be increased by tapping the card-board. The arrangement wilUbe that shown in Fig. 236. Note thatall the lines of force appear to enter the mouth of the cylinder: inpoint of fact, if we were to trace thelines of force throughout,…
