S 43 Principle of Superposition. — When several loads(concentrated or distributed) act upon a beam thetotal S.F. or B.M. at any section can be found by add-ing the S.Fs. and the B.Ms, at that sectiondue to eachload considered separately. This is known as the prin-ciple of superposition. It will be… … line the effect of the concentrated load, and the full linetheir combined effect or the total S.F. and B.M. Exercise 44. Sketch diagrams of S.F. and B.M., show-^- ing the effect of the loadings shown in Figs. 18 and 19 actingsimultaneously. 44 ■ MECHANICS OF MATERIALS Bending Moments by Means of…
