Kg. 1.—Bevelled Pole ShoeI, Fringe ol flux. cated in fig. 1, in order to obtain a goodfringing of the magnet flux. Skewed Pole Shoes.—This is one of themethods adopted with a view to obtaining asinusoidal distribution of flux in the air gap.Two forms of the arrangement are indicated … Fig. 3.—Skewed Pole Shoes P, Pole pitch. 8, Solid pole shoe. L, Laminated pole ehoaI, Outline of pole core. in fig. 2. See also Eccentric Pole Face;Pole, Comb.Pole Shoes, Chamfering of. See Bevelled Pole Shoes under Pole Shoe. Pole Shoes, Laminated. See Lami-nated. Pole Span. See Pole Arc; Angle…
