The microscopy of vegetable foods : with special reference to the detection of adulteration and the diagnosis of mixtures (1906)
Winton, Andrew Lincoln, 1864-1946, Moeller, Josef, 1848-1924 · New York : John Wiley & Sons · leaf 156
Fig. 102. Buckwheat (Fagopyrum esculenlum). Cross section of the pericarp at oneof the angles showing the epicarp, the hypoderm of sclerenchyma elements with fibro-vascular bundle {g), the brown parenchyma {p), and the inner layers of obliteratedcells. X160. (MOELLER.) with a scalpel, after boiling… … Fig. 103. Buckwheat. Isolated elements of the pericarp, o epicarp; p parenchyma(the upper group from a bundle); / hypoderm fibers; ep inner epidermis; sp spiralvessel. X160. (MoELLER.) I. The Epicarp Cells (0) are elongated, rounded quadrilateral andrange up to 100 fi in length and 20 ;i in…
Plant anatomy · Food adulteration and inspection · Microscopy
