Willoughby, George Alonzo, 1894- · Peoria, Ill. : Manual Arts Press · leaf 34
sure isapplied. Electricity will not flow out the end of a wire orother conductor. Before it is possible to make electricity 28 FLOW OF ELECTRICAL CURRENTS; CIRCUITS 29 flow, it is necessary to provide a complete circuit for it; thatis, there must be a continuous conductor, or series of… … Fig. 11. Illustrating the fact that water flows slowly thru a smallpipe, but rapidly thru a large one, just as electricity flows slowlythru a small wire, but rapidly thru a large one. water circuit formed by making two connections to a tank.No water will flow if a closed circuit is formed by…
Electricity · Electrical engineering
