n that manner one wire is done away with (Fig.22). BATTERY-LIGHTING CIRCUITS 43 38. Parallel and Series Connecting of Lamps.—Be-cause of the use of two different methods of connecting lampson an automobile, it is advisable to give a brief description ofthese two methods at this time. These two… … Fig. 22. A very simple one-wire system. Theframe of the automobile takes the place of theother wire. 6-V Battery Rarollel
