Willoughby, George Alonzo, 1894- · Peoria, Ill. : Manual Arts Press · leaf 48
Fig. 22. A very simple one-wire system. Theframe of the automobile takes the place of theother wire. 6-V Battery Rarollel … Fig. 23. Two lamps (6-volt) connected in parallel to a 6-voltstorage battery. Each lamp operates independently of the other. to the two wires. It will be seen that if one of the lamps iscompletely removed when they are connected in this manner,the other is unaffected. By series connecting two lamps…
Electricity · Electrical engineering
