line of the base-board, just below the part where themilled screw traverses backwards and forwards in making thefocus, a hole with slanting sides is cut through. A light brassdouble beam arm hangs on the milled head, and is clamped, whenrequired, by a small clamping screw at the centre, to the… … [To face page 1S8.] ■WITH THE MICEOSCOPE. 159 up the clampiiig screw is turned to release the beam, and the focus-sing-screw now rotates easily ; when the camera is drawn to thedistance required, the clamping screw is made to fix the beam.The focussing eye-piece is held by one hand, while the…
