FIG. B74.—COOK THREE-BOLT CLAMP. U-bolt clamps sustain loads of from 600 to 2000 pounds withoutslipping of the guy wire; two-bolt clamps from looo to 4500 pounds,and three-bolt clamps from iioo up to 6000 pounds. o > 2 Ci … 796 AMERICAN TELEPHONE PRACTICE. A thimble (Fig. 575) of galvanived steel is used for attaching theguy wire to the anchor rod, as shown in Fig: 569. The wire used in guying may consist of one or more strands ofNo. 9 or ID B. & S. steel wire twisted together, but a better plan isto use the…
